Mayflower®-II-AM5
Rugged 19” system (4U) with powerful AMD® Ryzen™ CPU for industrial environments
- High-Performance with AMD® Ryzen™ 7000 CPUs
- Capable for complex system configurations
- Robust full-industrial components for 24/7 operation
- Drive cages with anti-vibration design, hold-down clamps and washable air filters
System Description
This high quality 4U 19″ IPC is perfect for complex system configurations. With room for mainboards up to ATX form factor and very good ventilation, it supports high performance processors. An anti-vibration design of the drive cages, coupled with hold-down clamps, makes this industrial PC ideal for use in harsh, industrial environments. The two drive cages offer 4x 3.5″ and 3x 5.25 drive bays for removable hot-swap frames. Lockable front doors with integrated washable air filters protect drives and controls. Power supply with 400 Watt AC power supply, optionally available with redundant power supply. This industrial computer provides optimal functionality and safety during continuous operation.
Additional information
Mainboard / Backplane | Industrial Mainboard (ATX), 24/7 operation, long-term available |
---|---|
Processor | AMD® Ryzen™ 7000 series |
RAM | 4x DDR5 DIMM |
Graphic Card | Onboard AMD® Radeon™ |
Mass Storage | Internal: 2x M.2 (M-key, type: 2280) |
I/O | 2x 2.5 GBit LAN (RJ45) |
Power Supply | 90 ~ 264 VAC, 400 Watt |
Expansions (mechanical) | 1x PCIe x16 (Gen 5) |
Chassis | 19" 4 U rackmount chassis |
Dimensions (W x H x D) | 430 x 176 x 465 mm |
Cooling | Active, 1x 120 mm fan |
Operating Temperature | 0° ~ 50° C |
Storage Temperature | -40° ~ 80° C |
Relative Humidity (operation) | 0 ~ 95 % (non condensing) |
Supported Operating Systems | Microsoft® Windows® 11 |
Features | Watchdog Timer |
